贯通式同相供电系统中的电力电子变换器研究POWER　ELECTRONIC　CONVERTERS　IN　ADVANCED　COPHASE　TRACTION　POWER　SUPPLY　SYSTEM

This book focuses on analysis, modulation, simulation, and prototype verification of the power electronic converters in advanced co-phase traction power supply systems. Firstly, the grid-connected characteristic is introduced in the grid-connected traction power supply system. Then, the detailed circuits analysis, control, and modulation of grid-connected three-phase converter, single-phase converter, clamped multi-level three-phase to single-phase converter, modular multi-level three-phase to single-phase converter, and two-phase to single-phase converter in advanced co-phase system are analyzed and discussed in different chapters separately. It's also serves as an excellent reference for the study and research of power electronics related specialties.

1 Introduction

1.1 Brief Introduction to Electrification Development in Railway Transport Field

1.1.1 Development of Electrified Railway and High-Speed Railway

1.1.2 Overview of Electrified Railway Development in China

1.2 Brief Introduction to Research and Application of Traction Power Supply System

1.2.1 Overview of Traction Power Supply Technology Abroad

1.2.2 Overview of Traction Power Supply System in China

1.2.3 Existing Improvement Solutions for Traction Power Supply System

1.2.4 Characteristics of Ideal Traction Power Supply Systems

1.3 Overview of Research and Application of Co-phase Traction Power Supply

1.4 Overview of Research on Advanced Co-phase Traction Power Supply

1.5 Balance Principles for Common Types of Traction Transformers

1.6 Converter Topology in Advanced Co-phase Traction Power Supply System

1.6.1 Three-Phase-to-Single-Phase Converter Topology

1.6.2 Two-Phase-to-Single-Phase Converter Topology

1.6.3 Single-Phase-to-Single-Phase Converter Topology

1.6.4 Multilevel Conversion Circuit Topology

1.7 Summary

References

……
